2010-05-19
Network Virtualization
- Open vSwicth - multilayer virtual switch (2010-05-05 補充, 2009-01-20)
- Xen Cloud Platform 預設的網路集線器(switch)
- Open vSwitch reaches 1.0 - (2010-05-19)
- [官網] http://openvswitch.org/
- [套件] 目前尚未看到有人打包套件,應該是因為 Open vSwitch 計畫到了 2010 八月才把原始碼公開吧!!
- 甚至可以取代原有的 Linux Bridge 工具 - Replacing a Linux Bridge with Open vSwitch,期待 Debian / Ubuntu 開始有人打包了....
- Debian sid 套件 - openvswitch-common
- Debian sid 套件 - openvswitch-switch
- Debian sid 套件 - openvswitch-pki-server
- Debian sid 套件 - openvswitch-pki
- Debian sid 套件 - openvswitch-controller
- Citrix確定將在今年推出虛擬交換器 (2010-04-26)
- 初探虛擬交換器 (2010-07-19)
- Open vSwitch 安裝筆記 (2010-12-09)
- Open vSwitch – 開放虛擬交換標準 (2010-12-20)
- Cisco、Juniper 併購虛擬化與安全公司的背後
“如果妳閱讀過OpenStack, OpenFlow 以及Open vSwitch,妳會發現,世界已經不再面向設備,或者是交換機路由器,而轉向了CPU的軟件發展” Kindness說。
- 各 Hypervisior 比較之一 Virtual Switch (2009-12-28)
- OpenFlow - a way for researchers to run experimental protocols in the networks they use every day.
- 可以用來模擬實體網路,動態改變流量路由的工具
- [官網] http://www.openflowswitch.org
- [白皮書] OpenFlow: Enabling Innovation in Campus Networks
- [技術報告] FlowVisor: A Network Virtualization Layer (PDF)
Network
- ethtool - display or change ethernet card settings
- [簡介] Give Me Liberty or Give Me Eth
- [官網] http://sourceforge.net/projects/gkernel/
- [套件] debian - ethtool, ubuntu - ethtool
- 指令一:取得網路卡的驅動程式版本資訊 - 參考來源: Jserv's blog: ethtool 使用實例
ethtool -i eth0
- 透過指令可以使特定網卡的燈號閃爍數秒 - 參考來源: 準確判斷 eth0 是那一張實體網卡
ethtool -p eth0
- cdpr - Cisco Discovery Protocol Reporter - (2009-05-07)
- [參考] cdpr is a nifty little command which speaks the Cisco Discovery Protocol, allowing you to learn interesting things from your network.
- [官網] http://sourceforge.net/projects/cdpr/
- [套件] debian - cdpr, ubuntu - cdpr
- 蠻有趣的套件,還可以查出接在哪一個 swicth 上的哪個 port。當然如果 switch 不是 Cisco 出的,大概就看不到資訊了吧。
jazz@Wdebian:~$ sudo apt-get install cdpr jazz@Wdebian:~$ sudo cdpr cdpr - Cisco Discovery Protocol Reporter Version 2.2.1 Copyright (c) 2002-2006 - MonkeyMental.com 1. eth0 (No description available) 2. tap0 (No description available) 3. usbmon1 (USB bus number 1) 4. usbmon2 (USB bus number 2) 5. usbmon3 (USB bus number 3) 6. usbmon4 (USB bus number 4) 7. usbmon5 (USB bus number 5) 8. usbmon6 (USB bus number 6) 9. usbmon7 (USB bus number 7) 10. any (Pseudo-device that captures on all interfaces) 11. lo (No description available) Enter the interface number (1-11):1 Using Device: eth0 Waiting for CDP advertisement: (default config is to transmit CDP packets every 60 seconds) Device ID value: X.nchc.org.tw Addresses value: 140.110.X.X Port ID value: GigabitEthernet0/33
- 如何在 Linux System 當中偵測網路線是否有接上? - (2009-05-05)
$ cat /sys/class/net/eth0/carrier
